Aluminum Glass Door - 511
Model 511
Aluminum Glass Door model 511 is designed in sizes up to 16’2″ (4928 mm) wide and 16’1″ high (4902 mm). Featuring a narrow center stile width of 21/32″ (17 mm), these doors are sleek, attractive and permit maximum visibility. An array of glazing choices, top and bottom rail widths, finishes and special options customizes the 511 to satisfy nearly any project requirement.
Construction
| Product Specifications | |
|---|---|
| Standard Max Width | 16’2″ (4928 mm) |
| Standard Max Height | 16’1″ (4902 mm) |
| Panel thickness | 1 3/4″ (45 mm) |
| Material | 6063-T6 aluminum |
| Standard finish | 204R-1 clear anodized |
| Center stile width | 21/32″ (17 mm) |
| End stile width | 2 3/4″ (70 mm) |
| Top rail width | 2 3/8″ (60 mm)or 3 3/4″ (95 mm) |
| Top intermediate rail width | 3/4″ (19 mm) |
| Bottom intermediate rail width | 5/8″ (16 mm) |
| Bottom rail width | 2 3/8″ (60 mm) or 3 3/4″ (95 mm) or 4 1/2″ (114 mm) |
| Weatherseals | Bottom, flexible PVC |
| Standard springs | 10,000 cycle |
| Track | 2″ (51 mm) |
| Mounting | Angle |
| Operation | Manual pull rope |
| Hinges and fixtures | Galvanized steel |
| Lock | Galvanized, interior-mounted single unit |
Warranty
- 1-year limited
